Manual Datafox Evo 4.3 Page 128 Date: 27.12.2017 V 04.03.09.XX
5.9.3. DataOnCard on the access control reader
In order to be able to use on a standard ZK reader of the EVO or the PHG series, the following set-
tings must be made.
The functions for DataOnCard described in the previous chapters can only be set in the setup under
Control menu.
Now it is necessary to be able to access the access control reader under the control.
This is how you set it:
The reader on the access control reader (ZK) bus (RS485) is now activated via the Control menu
(Transponderleser der Bedienung)

Please note:
Only one access control reader (ZK) can be connected to the bus at any time.
Dip switch 1 and the termination of the bus must be set to "ON"
(Bus address 1).
