Evo 4.3’’ Multifunktionsterminal V4.X
Housing
Structure
Front panel made of aluminium and glass, capacitive touch, rear
housing shell plastic: ABS
Dimensions (width x height x
depth)
140 mm x 266 mm x 95 mm
Weight (Without power supply)
base unit 0,98 KG plus wall mount plate 0,235 KG
Individualization
Integrated backlit logo
Illuminated logo on panel 35 x 25mm D-Tile
Colour of Print
D-Tile, display frame and keypad freely designed
System
Clock
Real-time clock
Data storage
Flash
16 MB, 100,000 write cycles
Memory expansion (optional)
SD card, max 2 GB
Display
LCD
TFT: 480 x 272 pixels, active area 95,0 x 53,9 mm LED backlight
Keys
Type
Customizable Buttons on a capacitive glass touch with backlight
Size
Touch are overall: 95 x 156mm; touch area for user definable keys: 95
x 86mm
Power
Power Supply
12 V DC
Power
Base unit 4 watts, depending on the equipment up to max. 15 W
Clock / RAM buffering
Lithium Battery + goldcap
Environment values
Ambient temperature
-20 ° C to +70 ° C (Power Supply -20 ° C to +60 ° C)
Protection
IP 65 front side, IP54 complete
Software
Configuration program
Setup program (Datafox-Studio) to configure without programming
effort
Communication tools
http, DLL or C source code for inclusion in the application
Module extensions
For the extension to a variety of functions such as communication, inputs / outputs, sensors, ... are 7
expansion slots for modules.
Data transmission to
PC/Server
USB
Micro USB integrated
TCP / IP (optional)
TCP / IP operating with integrated TCP / IP stack, 10/100 Mbit
WLAN (optional)
integrated wireless LAN module, WLAN 802.11 bg and 802.11 n (only
2,4GHz)
GSM / GPRS (optional)
online via GSM and GPRS, mobile module quad band 850 / 900 /
1800 / 1900 MHz
RS485 (optional)
RS485 2-wire bus
USB host (optional)
for data transfer via USB stick, protection IP22
Bluetooth (optional)
Bluetooth module integrated; range up to max. 100 m
Readers Connection
RS232 external (optional)
Connection of bar code readers, magnetic card readers, etc. via mini-
DIN connector
Access Options
RS485 external
Connection of up to 3 busses with up to 8 external door modules /
access readers each
Door lock relay with Door Moni-
toring
1 relay changeover, 30 V AC, 30 V DC, 2 A, max. 60 W, 1 digital input
for door monitoring, ...
MDE Options
Module digital inputs
4 x digital input, electrically isolated, up to 100kHz, or 250Hz, Low
0,0...1,5V; High 3,5…30,0V
Module relay outputs
1 x NO, 1 x changeover contact, 30 V AC, 30 V DC, 2 A, max. 60 W
Module analog voltage inputs
4 x input, 15-bit resolution, accuracy ± 2% measuring range 0-10 V,
other ranges and functional insulation 230 V on request
Module analog inputs Current
4 x input, 15-bit resolution, accuracy ± 2%, measuring range 0-25 mA;
Functional insulation 230 V on request
Additional Options
Fingerprint
Fingerprint module integrated; sensor on the right below
Integrated transponder reader
125kHz, for example Unique, titanium, Hitag
13.56 MHz, e.g. Legic, Mifare, ISO14443, ISO15693, Simon Voss,
iButton, Nedap
GPS receiver / receiver
50 Channels, GPS L1 frequency C / A, Galileo Open Service L1
Bar code scanner integrated
1D or 2D bar code scanner
Column
Column for free putting
