Manual Datafox Evo 4.3 Page 122 Date: 27.12.2017 V 04.03.09.XX
5.8. RFID Reader
The RFID reader is built-in the Gerät. If this option is available, see the type label and the label on
the backside. By DatafoxStudioIV you can enable the RFID reader. For more information see the
manual of DatafoxStudioIV.
For reading a transponder you must hold it in front of the device. The reading area is marked with
the corresponding icon.
The following transponder readers can be built-in the EVO 4.3 :
EVO 4.3 with 125 kHz: Unique EM4102, Hitag1, Hitag2, HitagS, Hewi EM4450
LRW 8 cm R/W (LeseReichWeite “Read range” with card)
EVO 4.3 with Legic-Prime/Advant: LRW 4 cm R/W
EVO 4.3 with Mifare-Desfire: LRW 4 cm R/W für MifarePlus / 7 Byte UID notwendig
EVO 4.3 with i-Button-Leser: Touchmemory only reading
EVO 4.3 with HID 125kHz: LRW 4 cm only reading ProxPoint Plus 4065
EVO 4.3 with HID-iCLASS: LRW 4 cm only reading 13,56MHz
EVO 4.3 with Nedap: LRW 4 cm only reading
EVO 4.3 with SimonsVoss Smart-Relais: LRW optimum at approx. 20 cm! If the
transponder is too close, it might be not
recognized. (interface Siemens: CLS-
Signal=Yes).
