Manual Datafox Evo 4.3 Page 110 Date: 27.12.2017 V 04.03.09.XX
5.7.11. State message off access control
display
Assigned status message
0
module detected everything OK
3
module not in the list defined but found in the bus rs485
4
module in the list reader added but not found in the bus rs485
5
wrong Encryption password
6
login password is wrong
7
RFID-typ (Mifare, Legic, Unique, etc.) wrong
8
Failed to configure the module
9
No modules
10
the Key for communication with PHG-Modules was chonged
11
the Key for communication with PHG-Modules was not chonged
20
ID ok, accses succesful
21
ID is not in the list identification.
22
ActiveGeneral not correct.
23
Validity period does not fit.
24
Could not find the room. (group definitions)
25
Could not find am Time in time-table.
26
wait for PIN-input.
27
Pin wrong
28
threat code was input.
29
the PIN is right, accses successful.
30
the Master-PIN was input, accses successful.
31
PIN-Timeout.
32
Master-ID right, accses successful.
33
accses successful with PIN input.
34
Online-TP.
35
Online-PIN.
36
Make Action closing
40
digital output 1 is low (off)
41
digital output 1 is HIGH.(on)
42
digital output 1 is for the time ELAPSE, HIGH.
43
digital output 2 is low (off)
44
digital output 2 is HIGH.(on)
45
digital output 2 is for the time ELAPSE, HIGH.
46
digital output 3 is low (Off).
47
digital output 3 is HIGH.(On).
48
digital output 3 is for the time ELAPSE, HIGH.
49
digital output 4 is low (Off).
50
digital output 4 is HIGH.(On).
51
digital output 4 is for the time ELAPSE, HIGH.
52 #
digital output 5 is low (Off).
53 #
digital output 5 is HIGH.(On).
54 #
digital output 5 is for the time ELAPSE, HIGH.
55 #
digital output 6 is low (Off).
56 #
digital output 6 is HIGH.(On).
57 #
digital output 6 is for the time ELAPSE, HIGH.
# for new devices hardware version 4
