5.9. Data on Card
5.9.1. General infomations
With the Data on Card - function it is possible to write data with an individual structure on a tran-
sponder.
These data are provided in the form of a list of your application.
This list is loaded onto the terminal, and if you´re holding the transponder in front of the terminal the
data will be written and saved.
The following transponder-procedures support the Data on Card-function:
 Mifare
 Legic
 iCode
 MyD
For instance:
In buildings with an electronic closing cylinder should the actual daily authorization for the access be
wrote down on a transponder card.
The Personal ID will be checked and the corresponding current authorization - data will be written
on the card.
The terminal stores where the data is written to the ID card (e.g. via segment).
ID
Name
Data on Card
6796465
Max Mustermann
30313233343536374243444546303132333……
1256866
Heidi Testfrau
3031323334353637383941424344463031 ……
6987986
Franz Zufall
3031323334353637383941424344454630 ……
Access control system/ usage
Current permissions are created / set.
Informations about structure, Encryption,
CRC etc. do not matter.
Listing ID will be
checked and the corre-
sponding current au-
thorization - data will be
written on the card.
Doors with electronic locking
cylinder or similar.
The lists are
transferred to the
terminal via Talk.
The application
provides the data.
(Binary data)
The data is transferred to
the terminal via
DFCom.dll.
The terminal stores
where the data is
written to the ID card
(e.g. segment)
Current authorization yes / no
