5.7.5. Access control II with EVO-ZK-Plus-reader
5.7.5.1. Display and operation
The reader has a capacitive touch.
All images displayed by the reader and marked as standard below can be exchanged.
Display:
The entire display area is backed
by a touch screen.
With the DatafoxStudioIV, images
can be stored here for a gallery
display and for the necessary in-
puts/outputs.
See -> Configuration-> Display De-
signer.
Reading range of the transponder
with backlight in RGB colours.
The control of the LED is con-
trolled exclusively by the readers
firmware.
access denied = red -
access permitted = green -
Bios activated = blue -
