Manual Datafox Evo 4.3 Page 91 Date: 27.12.2017 V 04.03.09.XX
A Door with a Separate Reader
The EVO 4.3 is installed in a protected area inside a building and the reader is installed outside. The
terminal is access master and door-opener at the same time. The door opening relay is in the PZE-
MasterIV and thus installed in the protected area. The access identification captured by the reader
is transferred to the EVO 4.3 and analyzed by it. If access is permitted, the door is opened via the
relay in the .
Installation plan:
This ver- sion is used frequently and can be installed easily and economically
as shown in the figure above.
Wiring plan:
:
Reader table for this example
