Programming Mode
-
The following indications ONLY occur when the reader is in Programming
Mode
.
Indicator Description LED Beeper
Label Programming
Mode Entry
A valid programming label
has been scanned.
LED blinks continu-
ously
Reader sounds four
low frequency beeps.
Label Programming
Mode Reject
ion of
Label
A label has been rejected. N/A
Reader sounds three
tim
es at lowest fre-
quency and current
volum
e.
Label Programming
Mode A
cceptance of
Partial Label
In cases where multiple
labels m
u
st be scanned to
program one feature, this
indication acknowledges
each portion as it is suc-
cessfully scanned.
N/A
Reader sounds one
shor
t beep at hi
ghest
frequency and cur-
rent volume.
Label Programming
Mode A
cceptance of
Programming
Configuration option(s)
have
been successfully pro-
grammed via labels and the
r
e
ader has exited Program-
ming Mode.
N/A
Reader sounds one
high fr
equency beep
and 4 low frequency
beeps followed by
reset beeps.
Label Programming
Mode C
a
ncel Item
Entry
Cancel label has been
scanne
d.
N/A
Reader sounds two
ti
mes a
t low fre-
quency and current
vol
um
e.
Error Codes
Upon startup, if the reader sounds a long tone, this means the reader has not passed its automatic
Selftest and has entered FRU (Field Replaceable Unit) isolation mode. If the reader is reset, the
sequence will be repeated. Press and release the trigger to hear the FRU indication code.
The following table describes the LED flashes/beep codes
associated with an error found.
Number of LED Flashes/
Beeps
Error Corrective Action
1 Configuration
Contact Helpdesk
fo
r assistance
2 Interface PCB
6 Digital PCB
11 Imager
