93
Step Action
Displayed
Message
Comment(s)
5
Proceed according to the kind
of media being calibrated:
• Die-Cut Media --
Remove at least six
inches (15 cm) of the
beginning label material
from the liner. Install
the roll media or box
media. Adjust the
Media Sensor and then
press the ESC Key.
• Notched or Reflective
Media -- Install roll
media or box media.
Adjust the Media
Sensor accordingly,
and then press the ESC
Key.
• Continuous Media --
Install roll media or box
media. Adjust the
Media Sensor and
proceed to Step 6.
For die-cut media:
SCAN BACKING
PRESS ESC KEY
yyy
- or, for reflective
media:
SCAN MARK
PRESS ESC KEY
yyy
This sets the gap (or mark) value -
where ‘yyy’ is a numerical value
representing the sensor reading for
the TOF indicator.
Notes:
(1) Do not position a media
perforation
over the sensor when
taking any sensor reading.
(2) If using media with small notches
or reflective marks, ensure that the
labels exit straight from the printer.
(3) Do not
move the position of the
Media Sensor following this step.
6
Position label material (and
liner, if any) over the sensor
then press the ESC Key.
SCAN PAPER
PRESS ANY KEY
yyy
This sets the paper value - where ‘yyy’
is a numerical value representing the
sensor reading for the media.
Note: If using preprinted media,
ensure that the label area placed over
the sensor is free of preprinted text,
graphics, or borders.
