Datamax H Class User Manual

51
PRESENT
SENSOR
Controls the "on-demand" dispensation of labels (by inhibiting further label printing
until a previously printed label is removed) when the printer is equipped with the
Present Sensor or Peel and Present option, where:
MODE
Sets the option detection and response of the printer:
AUTO Automatically detects, enables the sensor, and sets the label stop location for the
option; if no option is detected, the operation will be ignored.
ENABLED Enables the sensor, and sets the label stop location for the option; if no option is
detected, a fault will be generated.
DISABLED Disables the option.
RETRACT
DELAY *
Programs a time delay period (1 - 255 x 10 milliseconds) that must elapse before the
retraction of the next label in the print process occurs, where:
070
milliseconds
Is the Default Setting.
CUTTER
Controls the cutting of media, where:
AUTO Automatically senses the presence of the cutter option. If detected, the cutter is
enabled; otherwise, the operation will be ignored.
ENABLED Enables cutting. If the cutter is not detected, a fault will be generated.
DISABLED Disables the option.
SCANNER
Controls the Linear Scanner and the way bar codes are interrogated, where:
MODE
Sets the mode of Linear Scanner operation:
AUTO Is the Default Setting. Automatically senses the presence of the scanner option. If
present, the scanner is enabled; otherwise, the device is ignored.
ENABLED Enables scanning. (If the option is not detected, a fault will be generated.)
DISABLED Disables the option.
BARCODE
COUNT *
Sets the number (0 – 99) of bar codes to be read on each label. Appropriate for
most applications, the default setting enables Auto Count Mode, which allows a
variable number of bar codes to be read on every label and is appropriate for most
applications. However, imaged bar codes (those sent as bit maps from the host)
can only be recognized by entering the minimum number that are to be read on
each label. (If you have questions regarding the way your bar codes are
generated, check with your software vendor.)
00 Is the Default Setting.
MIN READABLE
HEIGHT *
Ensures integrity by setting a vertical distance of the bar code that must have
identical decodes to be considered readable. For example, a setting of ¼ will
ensure that ¼ inch of the bar code is 100% readable. The setting range is 1/16 –
½ inch (1.5 – 12.5 mm), and Disabled. The selected distance should not exceed
50% of the measured bar code height. When ‘Disabled’ is selected, the printer
defaults to a REDUNDANCY LEVEL setting of 2 to ensure integrity (see below).
DISABLED Is the Default Setting.

Datamax H Class Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Interface	Ethernet, Wireless
Media Sensor	Reflective
Media Types	Labels, Tags
Resolution	203 dpi
Media Thickness	0.002 to 0.01 inches (0.05 to 0.25 mm)
