Datamax I-Class Mark II Maintenance Manual

41
I-Class Mark II Maintenance Manual Troubleshootin
g
Fault Messages (continued)
Displayed
Message
Description Solution LED Status
Present Sensor
Remove Label
The present
sensor (if
equipped) has
detect a label
blocking the
sensor.
1) Remove the label if present.
2) The Present Sensor may be defective; replace.
Flashing Yellow
GREEN: OFF
GPIO
Waiting for
Signal
The GPIO option
card (if
equipped) is
awaiting a
signal from the
host or other
remote
equipment.
Refer to the GPIO Installation Instructions
included with the option or downloaded from
www.datamax-oneil.com.
RED: OFF
GREEN: ON
GPIO
Waiting for Data
The GPIO option
card (if
equipped) is
awaiting data
from the host.
Refer to the GPIO Installation Instructions
included with the option or downloaded from
www.datamax-oneil.com.
RED: OFF
GREEN: ON

Datamax I-Class Mark II Specifications

General

Power Supply	100-240 VAC, 50-60 Hz
Print Resolution	203 dpi
Print Width	4.09 inches
Memory	16 MB DRAM, 8 MB Flash
Connectivity	USB, Serial, Ethernet
Media Handling	Roll-fed
Media Width	1.0" – 4.65" (25.4 mm – 118 mm)
Media Thickness	0.0025" – 0.010" (0.0635 mm – 0.254 mm)
Ribbon Width	1.0" – 4.5" (25.4 mm – 114.3 mm)
Ribbon Length	1968 feet (600 meters)
Print Speed	up to 12 ips
Dimensions	12.7" H x 12.6" W x 18.6" D (322.6 mm H x 320 mm W x 472.4 mm D)
