LS10 Installation and Operating Guide Page 58
LS10 Installation & Operating Guide Document # 9301H66300 Ver. 1.01
c. Small, cross to L/R – The Left Surround will be crossed to the Left Front speaker and Right
Surround will be crossed to the Right Front speaker. Select the desired crossover filter
frequency and slope. In order to use this option, the Left and Right Front speakers should be
defined as Large. If not, an error message will appear on the screen.
d. Phantom Surround – Use this if Left and Right Surround speakers are not installed. The Left
Surround channel is mixed with the Left Front speaker and the Right Surround channel is mixed
with the Right Front speaker. The offset can be adjusted.
8. Lb, Rb – Left Back and Right Back speaker options:
a. Large – (default) Speaker can handle full range of frequencies.
b. Small – Cross with the subwoofer(s). Select the desired crossover filter frequency and slope.
c. Small, cross to L/R – The Left Back will be crossed to the Left Front speaker and Right Back
will be crossed to the Right Front speaker. Select the desired crossover filter frequency and
slope. In order to use this option, the Left and Right Front speakers should be defined as Large.
If not, an error message will appear on the screen.
9. Lw, Rw – Left Wide and Right Wide speaker options:
a. Large – (default) Speaker can handle full range of frequencies.
b. Small – Cross with the subwoofer(s). Select the desired crossover filter frequency and slope.
10. HL, HR – High Left and High Right speaker options:
a. Large – (default) Speaker can handle full range of frequencies.
b. Small – Cross with the subwoofer(s). Select the desired crossover filter frequency and slope.
c. Small, cross to L/R – The High Left will be crossed to the Left Front speaker and High Right
will be crossed to the Right Front speaker. Select the desired crossover filter frequency and
slope. In order to use this option, the Left and Right Front speakers should be defined as Large.
If not, an error message will appear on the screen.
11. HC – High Center speaker options:
a. Large – (default) Speaker can handle full range of frequencies.
b. Small – Cross with the subwoofer(s). Select the desired crossover filter frequency and slope.
c. Small, cross to C – The High Center will be crossed to the Center speaker. Select the desired
crossover filter frequency and slope. In order to use this option, the Center speaker should be
defined as Large. If not, an error message will appear on the screen.
