LS10 Installation and Operating Guide Page 59
LS10 Installation & Operating Guide Document # 9301H66300 Ver. 1.01
12. HLs, HRs – High Left Surround and High Right Surround speaker options:
a. Large – (default) Speaker can handle full range of frequencies.
b. Small – Cross with the subwoofer(s). Select the desired crossover filter frequency and slope.
c. Small, cross to Ls/Rs – The High Left Surround will be crossed to the Left Surround speaker
and High Right Surround will be crossed to the Right Surround speaker. Select the desired
crossover filter frequency and slope. In order to use this option, the Left Surround and Right
Surround speakers should be defined as Large. If not, an error message will appear on the
screen.
13. T – Top speaker options:
d. Large – (default) Speaker can handle full range of frequencies.
e. Small – Cross with the subwoofer(s). Select the desired crossover filter frequency and slope.
f. Cross to L/R/Ls/Rs – Top speaker will be crossed with the Left Front, Right Front, Left
Surround, and Right Surround speakers. In order to use this option, the L, R, Ls, and Rs
speakers should be defined as Large. If not, an error message will appear on the screen.
14. Return to the Bass Management Setup screen and verify the configuration. All speaker
configuration options are described in text next to the speaker. This completes the bass
management setup.
