LS10 Installation and Operating Guide Version 1.01
Appendix A. Connector Pin-outs A-3 Document #: 9301H66300 Ver. 1.01
Infrared Remote Controller Input
IR REMOTE INPUT – 3.5mm STEREO
JACK
Pin Description
TIP +5V
RING Signal
SLEEVE Ground
Trigger Out
TRIGGER OUT 12V – 3.5mm MONO
JACK
Pin Description
TIP Trigger out
SLEEVE Ground
