3.2 TERMINAL SPECIFICATION
Connection type Two part connector.
• Male part fitted to
module
• Female part supplied in
module packing case -
Screw terminal, rising
clamp, no internal
spring.
Example showing cable entry and screw
terminals of a 10 way connector
Minimum cable size 0.5 mm² (AWG 24)
Maximum cable size 2.5 mm² (AWG 10)
NOTE: - For purchasing additional connector plugs from DSE, please see the section
entitled Maintenance, Spares, Repair and Servicing elsewhere in this document.
3.3 POWER SUPPLY REQUIREMENTS
Minimum supply voltage 8 V continuous
Cranking dropouts
Able to survive 0 V for 50 mS providing the supply was at least
10 V before the dropout and recovers to 5 V afterwards.
Maximum supply voltage 35 V continuous (60 V protection)
Reverse polarity protection -35 V continuous
Maximum operating current
300 mA at 24 V
600 mA at 12 V
Maximum standby current
160 mA at 24 V
330 mA at 12 V
3.3.1 PLANT SUPPLY INSTRUMENTATION DISPLAY
Range 0 V-70 V DC (note Maximum continuous operating voltage of
35 V DC)
Resolution 0.1 V
Accuracy 1 % full scale (±0.7 V)
