Installation
42
4.1.2 ANALOGUE SENSOR
PIN
No
DESCRIPTION CABLE
SIZE
NOTES
16 Sensor Common Return
0.5m
AWG 20
Return feed for sensors
17 Oil Pressure Input
0.5m
AWG 20
Connect to Oil pressure sensor
18 Coolant Temperature Input
0.5m
AWG 20
Connect to Coolant Temperature sensor
19 Fuel sensor input
0.5m
AWG 20
Connect to fuel sensor (user configurable) can also be
configured to flexible sensor for alternative use.
20 Flexible sensor 2
0.5m
AWG 20
Connect to additional sensor (user configurable)
NOTE:- Terminal 21 is not fitted to the controller.
NOTE: - It is VERY important that terminal 16 (sensor common) is soundly connected to
an earth point on the ENGINE BLOCK, not within the control panel, and must be a sound
electrical connection to the sensor bodies. This connection MUST NOT be used to provide an
earth connection for other terminals or devices. The simplest way to achieve this is to run a
SEPARATE earth connection from the system earth star point, to terminal 16 directly, and not
use this earth for other connections.
NOTE: - If you use PTFE insulating tape on the sensor thread when using earth return
sensors, ensure you do not insulate the entire thread, as this will prevent the sensor body
from being earthed via the engine block.
