3.7 OUTPUTS
Ten (10) outputs are fitted to the controller.
3.7.1 OUTPUTS A & B
Type Normally used for Fuel / Start outputs. Fully configurable for other purposes if the
module is configured to control an electronic engine. Supplied from Emergency Stop
terminal 3.
Rating 15A resistive @ 35V
3.7.2 CONFIGURABLE OUTPUTS C & D (LOAD SWITCHING)
Type Fully configurable volts free relays. Output C – Normally Closed, Output D – Normally
Open
Rating 8A resistive@ 250V AC
Protection Protected against over current & over temperature. Built in load dump feature.
3.7.3 OUTPUTS E,F,G,H, I, J
Number
6.
A future firmware update to the controller will enable an additional two outputst.
Check with DSE Technical Support for further details.
Type Fully configurable, supplied from DC supply terminal 2.
Rating 2A resistive @ 35V
