Manual DEHLER 39
15 - 72
2. Description of the boat
2.1 Main data
Overall length Ol 11.80 m
Length waterline Lwl 11.03 m
Maximum beam Bmax 3.85 m
Beam hull Bh 3.80 m
Draft hull Hull 0.50 m
Max. draft standard keel Tmax 1.98 m
Draft regatta keel (optional) Tmax 2.35 m
Side height midship Db 1.22 m
Transport height standard keel without support HT 4.02 m
Transport height regatta keel without support Hr 4.39 m
Full height mast* HD 18.30 m
Full height mast with additional antennas Hmax D
• The full height can be critical when you have to pass undr a bridge or a high voltage line.
It is the height above the waterline until the highest point of the mast. It is measured
without possible antennas nor a radar reflector but taking into account the measurement
for the WINDEX. Please correct the measurement if you install any additional gear and
mark it in the last line of the main data.
