Manual DEHLER 39
25 - 72
3.6 Shrouds, stays and halyards
Dimensions
Forestay Type Dyform 10mm Ø 16221 mm
Backstay Type Dyform 8 mm Ø 13880 mm
Bridles Type 8 mm Ø 7 x 19 mm
D4 / V 3 Type Dyform 8 mm Ø 7035 mm
D3 Type Dyform 7mm Ø 3711 mm
D2 Type Dyform 7mm Ø 3745 mm
V2 Type Dyform 7mm Ø 3638 mm
D1 Type Dyform 10mm Ø 4714 mm
V1 Type Dyform 10mm Ø 4713 mm
3.7 Running rigging
Dimensions
Main halyard 10 mm Ø 38m colour neon green
Jig halyard 10 mm Ø 35m colour light blue
Spinnaker halyard top 12 mm Ø 39m colour red*
Spinnaker halyard 10 mm Ø 34m colour red*
Top shroud 12 mm Ø 13m colour red*
Kicking strap 12 mm Ø 13 m colour blue/white*
Outhaul 12 mm Ø 13 m colour blue/white
Reefing line I 10 mm Ø 21,5m colour blue/white
Reefing line II 10 mm Ø 23m colour blue/white
FIGURE: SHROUDS/STAYS
2 Flag lines 4mm Ø 9m colour white
* Optional execution
