Material
Selection of one of the programmed materials, which are used to calculate the bending
depths. The control contains 6 pre-programmed materials. In total, 99 materials can be
programmed on the control. The materials can be programmed on the Materials page in
the Settings mode.
Functions
Connect
The function Connect is to have a possibility to connect certain programs to each other. This
option can be used to produce 3-dimensional products out of two programs.
+Connect program
With the function Connect it is possible to create a 3-dimensional product. The control
automatically executes the bend sequences in the different directions in succession. You
program the control as follows:
1 Create the product in one direction.
2 Create the product in the other direction.
There are now two bend programs of one product in two directions. You connect these
programs as follows:
1 Select the program with the bend sequence in the direction which you want to
execute in the first place. You select the program of the product via the ’product
library’.
2 Go to the Program mode and select Product properties.
3 In the Product properties window you select the function Connect and Connect
program.
4 Select the product ID of the product in the other direction.
5 Select the second program as in step 1. Repeat steps 2 to 4. If you want to con-
nect two programs, as in this example, you enter the product ID of the first pro-
gram. The cycle is closed.
When you want to execute more than two programs in succession (not necessarily to create a
3-dimensional product) the second program must refer to the third. The third program to the
fourth and so on. The final program of the cycle must always refer to the first program.
To produce products with connected programs the next four actions are necessary.
1 Select the first program
2 Select the Automatic mode
3 Program the amount of products you want to produce with the ’stock count’
Tensile
strength
(N/mm²)
E-module
(N/mm²)
Strain
hardening
exponent
1 = Steel
2 = Aluminium
3 = Zinc
4 = Stainless steel
470
250
200
750
210.000
210.000
94.000
210.000
0.23
0.26
0.20
0.32
