V0817, 6.5
the Settings mode.
Tools
Punch
The name (ID) of the selected punch. Tap to modify or select from the punch library.
Die
The name (ID) of the selected die. Tap to modify or select from the die library.
Auxiliary axes
Auxiliary axis
If you have one or more auxiliary axes (for instance an X-axis, R-axis or Z-axis) the
parameters of these axes appear here.
Retract
The retract distance of the axis during the bend. The "backgauge retract" is started at
the pinching point.
Speed
Speed of the axis in the current bend. Speed can be programmed in a percentage of the
maximum possible speed.
The above mentioned parameters can be programmed and modified as required. After
pushing the Start button the programmed parameters are active.
