Control panel assembly
Removing the control panel
Prerequisites
1 Follow the safety guidelines listed in safety instructions section.
2 Follow the procedure listed in the Before working inside your appliance section.
3 Keep the Phillips #2 screwdriver handy.
Steps
1 Using a Phillips #2 screwdriver, remove the screw(s) securing the control panel to the chassis.
CAUTION: Do not use excessive force when removing the control panel as it can damage the connectors.
2 From inside the appliance, push the control panel out of the chassis.
3 Remove all the cables connecting the control panel to the chassis.
Installing and removing components 113
