2 Turn off the appliance, including any attached peripherals.
3 Disconnect the appliance from the electrical outlet and disconnect the peripherals.
4 If installed, remove the optional bezel. For more information, see the Removing the optional front bezel section.
Steps
1 Rotate the latch release lock counter clockwise to the unlocked position.
2 Lift the latch toward the back of the appliance.
The appliance cover slides back and the tabs on the appliance cover disengage from the slots on the chassis.
NOTE: The position of the latch may vary depending on the configuration of your appliance.
3 Hold the cover on both sides, and lift the cover away from the appliance.
Figure 14. Removing the appliance cover
1
latch release lock 2 latch
3 appliance cover
Next steps
1 Install the appliance cover.
Installing the appliance cover
Prerequisites
1 Follow the safety guidelines listed in the Safety instructions section.
2 Ensure that all internal cables are connected and placed out of the way, and no tools or extra parts are left inside the appliance.
Installing and removing components
53
