Technical specifications
The technical and environmental specifications of your appliance are outlined in this section.
Chassis dimensions
Figure 11. Chassis dimensions of Dell EMC VxRail™ P470/P470F/V470/V470F appliance
Table 10. Dimensions of Dell EMC VxRail
™ P470/P470F/V470/V470F appliance
Appliance Xa Xb Y Za (with
bezel)
Za (without
bezel)
Zb Zc
16 x 2.5-inch hard drive 482.4 mm 434.0 mm 42.8 mm 35.0 mm 20.4 mm 731.0 mm 752.1 mm
Chassis weight
The Dell EMC VxRail™ P470/P470F/V470/V470F appliance supports 16 x 2.5-inch hard drive with maximum weight of 31.4 kg (69.23 lb)
