Dell EMC VxRail P470 - Installing the Control Panel

Figure 69. Removing the information tag
1 information tag 2 tab
3 slot
Next steps
1 Replace the control panel.
2 Follow the procedure listed in the After working inside your appliance section.
Installing the control panel
Prerequisites
1 Follow the safety guidelines listed in safety instructions section.
2 Follow the procedure listed in the Before working inside your appliance section.
3 Keep the #2 Phillips screwdriver ready.
Steps
1 Replace the blank information tag in the new control panel with the information tag retained from the old control panel.
NOTE
: Information tag lists appliance information such as Service Tag, NIC, and MAC address.
2 To install the information tag, push the information tag into the control panel slot.
3 Connect all the applicable cables to the control panel.
4 Slide the control panel into the slot in the chassis and secure the module with the screw.
Installing and removing components
115
