Steps
Locate the SD card slot on the internal dual SD module or the backplane expander board and press inward on the card to release it
from the slot and remove the card.
Next steps
Follow the procedure listed in the After working inside your appliance section.
Installing an internal SD card
Prerequisites
1 Follow the safety guidelines listed in the Safety instructions section.
2 Follow the procedure listed in the Before working inside your appliance section.
NOTE: To use an SD card with your appliance, ensure that the internal SD card port is enabled in the System Setup.
Steps
1 Locate the SD card connector on the internal dual SD module or the backplane expander board. With the label side facing up, insert
the contact-pin end of the card into the slot.
NOTE: The slot is keyed to ensure correct insertion of the card.
2 To lock the card into place, press it into the card slot.
Next steps
Follow the procedure listed in the After working inside your appliancesection.
Removing the internal dual SD module
Prerequisites
1 Follow the safety guidelines listed in the Safety instructions section.
2 Follow the procedure listed in the Before working inside your appliance section.
3 If installed, remove the SD cards.
NOTE
: Temporarily label each SD card with its corresponding slot number before removal. Reinstall the SD cards into
the corresponding slots.
Steps
1 Locate the internal dual SD module (IDSDM) on the system board. To locate the internal dual SD module connector, see the System
board connectors section.
2 Holding the pull tab, lift the IDSDM out of the appliance.
90
Installing and removing components
