Table 27. Memory configurations—two processors
Appliance
capacity (in
GB)
DIMM size (in GB) Number of DIMMs DIMM rank, organization,
and frequency
DIMM slot population
128 16 8 2R, x8, 2400 MT/s
2R, x8, 2133 MT/s
A1, A2, A3, A4, B1, B2, B3,
B4
256 16 16 2R, x8, 2400 MT/s
2R, x8, 2133 MT/s
A1, A2, A3, A4, A5, A6, A7,
A8, B1, B2, B3, B4,B5, B6,
B7, B8
384 16 24 2R, x4, 1866 MT/s A1, A2, A3, A4, A5, A6, A7,
A8, A9, A10, A11, A12, B1, B2,
B3, B4, B5, B6, B7, B8, B9,
B10, B11, B12
512 32 16 2R, x4, 2400 MT/s
2R, x4, 2133 MT/s
A1, A2, A3, A4, A5, A6, A7,
A8, B1, B2, B3, B4,B5, B6,
B7, B8
64 8 4R, x4, 2400 MT/s
4R, x4, 2133 MT/s
A1, A2, A3, A4, A5, A6, A7,
A8, B1, B2, B3, B4,B5, B6,
B7, B8
768 32 24 2R, x4, 1866 MT/s A1, A2, A3, A4, A5, A6, A7,
A8, A9, A10, A11, A12, B1, B2,
B3, B4, B5, B6, B7, B8, B9,
B10, B11, B12
64
16
4R, x4, 2400 MT/s
4R, x4, 2133 MT/s
A1, A2, A3, A4, A5, A6, A7,
A8, A9, A10, A11, A12, B1, B2,
B3, B4, B5, B6
1024 64 16 4R, x4, 2133 MT/s A1, A2, A3, A4, A5, A6, A7,
A8, A9, A10, A11, A12, B1, B2,
B3, B4, B5, B6
1536 64 24
4R, x4, 1866 MT/s
4R, x4, 2133 MT/s
A1, A2, A3, A4, A5, A6, A7,
A8, A9, A10, A11, A12, B1, B2,
B3, B4, B5, B6, B7, B8, B9,
B10, B11, B12
Removing memory modules
Prerequisites
CAUTION
: Many repairs may only be done by a certified service technician. You should only perform troubleshooting and simple
repairs as authorized in your product documentation, or as directed by the online or telephone service and support team.
Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions
that are shipped with your product.
1 Follow the safety guidelines listed in the Safety instructions section.
2 Follow the procedure listed in the Before working inside your appliance section.
3 Remove the cooling shroud.
Installing and removing components
61
