Dell EMC VxRail P470 - Removing a Hard Drive or a Solid State Drive from a Hard Drive Carrier

3 Press the release button on the front of the hard drive carrier and open the hard drive carrier handle.
4 Insert the hard drive carrier into the hard drive slot until the carrier connects with the backplane.
5 Close the hard drive carrier handle to lock the hard drive in place.
Next steps
Install the optional front bezel.
Figure 25. Installing a hot swappable hard drive
1
release button 2 hard drive or SSD carrier
3 hard drive or SSD carrier handle
Removing a hard drive or a solid state drive from a hard drive
carrier
Prerequisites
1 Keep the Phillips #1 screwdriver ready.
2 Remove the hot swappable hard drive carrier from the appliance.
Steps
1 Remove the screws from the slide rails on the hard drive carrier.
2 Lift the hard drive out of the hard drive carrier.
Installing and removing components
