Dell EMC VxRail P470 - Processor Specifications; PSU Specifications; Battery Specifications; Expansion Bus Specifications

Processor specifications
The Dell EMC VxRail™ P470/P470F/V470/V470F appliance supports two Intel Xeon E5-2600 v4 product family processors.
PSU specifications
The Dell EMC VxRail™ P470/P470F/V470/V470F appliance supports two AC or DC redundant power supply units (PSUs).
Table 11. PSU specifications
PSU Class Heat dissipation
(maximum)
Frequency Voltage
1100 W AC Platinum 4100 BTU/hr 50/60 Hz 100–240 V AC, autoranging
1100 W DC N/A 4416 BTU/hr N/A –(48–60) V DC
NOTE: Heat dissipation is calculated by using the PSU wattage rating.
NOTE: This appliance is also designed to connect to the IT power systems with a phase to phase voltage not exceeding 230 V.
Battery specifications
The Dell EMC VxRail™ P470/P470F/V470/V470F appliance supports CR 2032 3.0-V lithium coin cell battery.
Expansion bus specifications
Table 12. Expansion card riser specifications
Expansion card riser PCIe slots on the riser Height Length Link
Riser 1 Slot 1 half-height low-profile x8
Riser 1 Slot 2 half-height low-profile x8
Riser 1 Slot 3 half-height low-profile x8
Riser 2 Slot 4 full-height full-length x16
Riser 2 Slot 5 full-height full-length x8
Riser 3 (alternate) Slot 6 full-height full-length x16
NOTE: When using slots 1 through 4 on the riser, ensure that both the processors are installed on the appliance.
Memory specifications
The Dell EMC VxRail™ appliance supports DDR4 registered DIMMs (RDIMMs) and load-reduced DIMMs (LRDIMMs). Supported memory
bus frequencies are 1866 MT/s, 2133MT/s, or 2400 MT/s.
Technical specifications
23
