Figure 48. Installing the GPU card
1
expansion card locking tab (3) 2 GPU card
3 PCIe card holder latch 4 expansion card latch
5 expansion card riser 3
Next steps
Follow the procedure listed in the After working inside your appliance section.
Internal dual SD Module
The Internal Dual SD module (IDSDM) provides you with a redundant SD card solution. The IDSDM card offers the following feature:
• Dual card operation — Maintains a mirrored configuration by using SD cards in both the slots and provides redundancy.
NOTE
: The IDSDM on the VxRail appliance is pre-configured for appliance bare metal recovery. Do not change any of the
settings.
Removing an internal SD Card
Prerequisites
1 Follow the safety guidelines listed in the Safety instructions section.
2 Follow the procedure listed in the Before working inside your appliance section.
Installing and removing components
