Item Connector Description
12 J_COM1 Serial connector
13 J_IDRAC_RJ45 iDRAC7 connector
14 J_CYC Appliance identification connector
15 CYC_ID Appliance identification button
16 J_RISER_2AX Riser 2 connector
17 J_RISER_1AX Riser 1 connector
18 J_RISER_2BX Riser 2 connector
19 J_RISER_1BX Riser 1 connector
20 J_RISER_3AX Riser 3 connector
21 J_SATA_B SATA connector
22 J_RISER_3BX Riser 3 connector
23 J_USB_INT Internal USB port
24 J_STORAGE Storage controller card connector
25 J_SATA_A SATA connector
26 BAT Battery connector
27 CPU2 Processor socket 2
28 J_FAN1U_7 Cooling fan connector
29 B1, B5, B9, B2, B6, B10 Memory module sockets
30 J_BP3 Hard drive backplane power connector
31 J_FAN1U_6 Cooling fan connector
32 J_BP_SIG2 Backplane signal connector 2
33 J_FAN1U_5 Cooling fan connector
34 J_BATT_SIG Battery signal connector
35 J_FAN1U_4 Cooling fan connector
36 A1, A5, A9, A2, A6, A10, B3, B7, B11, B4, B8, B12 Memory module sockets
37 J_FAN1U_3 Cooling fan connector
38 J_FAN2U Cooling fan connector
39 J_FAN1U_2 Cooling fan connector
40 A12, A8, A4, A7, A11, A3 Memory module sockets
41 J_FAN1U_1 Cooling fan connector
42 J_CTRL_PNL Control panel connector
43 CPU1 Processor socket 1
44 J_FP_USB Front panel USB port
128 Jumpers and connectors
