Option Description
CAUTION: Switching the boot mode may prevent the appliance from booting if the operating system is
not installed in the same boot mode.
If the operating system supports UEFI, you can set this option to UEFI. Setting this field to BIOS allows
compatibility with non-UEFI operating systems. This option is set to BIOS by default.
NOTE: Setting this field to UEFI disables the BIOS Boot Settings menu. Setting this field to BIOS
disables the UEFI Boot Settings menu.
Boot Sequence
Retry
Enables or disables the Boot Sequence Retry feature. If this option is set to Enabled and the appliance fails to
boot, the appliance reattempts the boot sequence after 30 seconds. This option is set to Enabled by default.
Hard-Disk Failover Specifies the hard drive that is booted in the event of a hard drive failure. The devices are selected in the Hard-
Disk Drive Sequence on the Boot Option Setting menu. When this option is set to Disabled, only the first hard
drive in the list is attempted to boot. When this option is set to Enabled, all hard drives are attempted to boot in
the order selected in the Hard-Disk Drive Sequence. This option is not enabled for UEFI Boot Mode.
Boot Option
Settings
Configures the boot sequence and the boot devices.
BIOS Boot Settings Enables or disables BIOS boot options.
NOTE: This option is enabled only if the boot mode is BIOS.
UEFI Boot Settings Enables or disables UEFI Boot options. The Boot options include IPv4 PXE and IPv6 PXE. This option is set to
IPv4 by default.
NOTE: This option is enabled only if the boot mode is UEFI.
Choosing the appliance boot mode
NOTE
: VxRail appliances require the boot mode to be set to BIOS.
System Setup enables you to specify one of the following boot modes for installing your operating system:
• BIOS boot mode (the default) is the standard BIOS-level boot interface.
• Unified Extensible Firmware Interface (UEFI) (the default) boot mode is an enhanced 64-bit boot interface. If you have configured
your appliance to boot to UEFI mode, it replaces the system BIOS.
1 From the System Setup Main Menu, click Boot Settings, and select Boot Mode.
2 Select the boot mode you want the appliance to boot into.
CAUTION
: Switching the boot mode may prevent the appliance from booting if the operating system is not installed in
the same boot mode.
3 After the appliance boots in the specified boot mode, proceed to install your operating system from that mode.
Changing the boot order
About this task
NOTE
: Dell EMC does not recommend changing boot order.
You may have to change the boot order if you want to boot from a USB key or an optical drive.The following instructions may vary if you
have selected BIOS for Boot Mode.
Steps
1 On the System Setup Main Menu screen, click System BIOS > Boot Settings.
2 Click Boot Option Settings > Boot Sequence.
3 Use the arrow keys to select a boot device, and use the plus (+) and minus (-) sign keys to move the device down or up in the order.
Pre-operating system management applications
33
