Figure 1. Supported configurations
1
Cooling fan in the cooling fan assembly (6) 2 Processor (2)
3 DIMMs (24) 4 PCIe card holder
5 Internal USB port 6 Power supply unit (2)
7 Expansion card riser 3 8 Network daughter card
9 Expansion card riser 2 10 Expansion card riser 1
11 Hard drive backplane
Overview 9
