Remove the DADF feed roller assembly and remove the document by gently pulling it straight up.

d

Insert the DADF feed roller assembly and press down the release lever.

If the document is jammed in the paper exit area:

e

Remove the jammed document from the document output tray.

Clearing Jams 516
