16

Close the right side cover.

17

Close the rear cover.

Cleaning the Raster Optical Scanner (ROS) Window

To prevent deterioration of printing quality due to stains inside the printer, clean inside the printer regularly by using

the cleaning rod whenever you replace drum cartridges.

1

Open the right side cover.

Maintaining Your Printer 496
