1466 | Virtual Routing and Forwarding (VRF)
www.dell.com | support.dell.com
Example
Usage
Information
After you set the CAM size on an Exascale platform, you must select and enable VRF microcode, and
reload the system to activate the CAM profile (see the example above).
Related
Commands
FTOS(conf)#cam-profile test
FTOS(conf-cam-prof-test)#microcode vrf
FTOS(conf-cam-prof-test)#enable
CAM profile 'abc' is currently enabled.
Do you want to disable it and continue? [yes/no]: y
Updating the cam-profile will need a chassis reboot.
System configuration has been modified. Save? [yes/no]: y
Nov 3 21:57:27: %RPM0-P:CP %FILEMGR-5-FILESAVED: Copied running-config to
startup-config in flash by default
Synchronizing data to peer RPM
!!!!!
Proceed with reload [confirm yes/no]: y
FTOS# show cam-profile
-- Chassis CAM Profile --
CamSize : 40-Meg
: Current Settings
Profile Name : test
Microcode Name : VRF
L2FIB : 15K entries
Learn : 1K entries
L2ACL : 5K entries
System Flow : 102 entries
Qos : 500 entries
Frrp : 102 entries
L2pt : 266 entries
IPv4FIB : 256K entries
IPv4ACL : 16K entries
IPv4Flow : 24K entries
Mcast Fib/Acl : 9K entries
Pbr : 1K entries
Qos : 10K entries
System Flow : 4K entries
EgL2ACL : 2K entries
EgIpv4ACL : 4K entries
Mpls : 60K entries
IPv6FIB : 12K entries
IPv6ACL : 6K entries
IPv6Flow : 6K entries
Mcast Fib/Acl : 3K entries
Pbr : 0K entries
Qos : 1K entries
System Flow : 2K entries
EgIpv6ACL : 1K entries
GenEgACL : 0.5K entries
IPv4FHOP : 4K entries
IPv6FHOP : 4K entries
IPv4/IPv6NHOP : 12K entries
Reload the system after
setting the CAM Profile.
cam-profile ipv4-v6-vrf
Set the VRF CAM profile for IPv4 and IPv6 on the
E-Series Terascale.
