Access Control Lists (ACL) | 225
Defaults
Not configured
Command Modes
CONFIGURATION-EXTENDED-ACCESS-LIST
Command
History
Usage
Information
The order option is relevant in the context of the Policy QoS feature only. See the “Quality of
Service” chapter of the FTOS Configuration Guide for more information.
When you use the log option, CP processor logs details about the packets that match. Depending on
how many packets match the log entry and at what rate, the CP may become busy as it has to log these
packets’ details.
The monitor option is relevant in the context of flow-based monitoring only. See Chapter 44, Port
Monitoring.
Table 9-2 lists the keywords displayed in the CLI help and their corresponding ICMP Message Type
Name.
Version 8.3.1.0
Added
dscp keyword.
Version 8.2.1.0 Allows ACL control of fragmented packets for IP (Layer 3) ACLs.
Version 8.1.1.0 Introduced on E-Series ExaScale
Version 7.4.1.0
Added support for non-contiguous mask and added the monitor option.
Version 6.5.10
Expanded to include the optional QoS
order priority for the ACL entry.
Note: When ACL logging and byte counters are configured simultaneously, byte counters
may display an incorrect value. Configure packet counters with logging instead.
Table 9-2. ICMP Message Type Keywords
Keyword ICMP Message Type Name
administratively-prohibited Administratively prohibited
alternate-address Alternate host address
conversion-error Datagram conversion error
dod-host-prohibited Host prohibited
dod-net-prohibited Net prohibited
echo Echo
echo-reply Echo reply
general-parameter-problem Parameter problem
host-isolated Host isolated
host-precedence-unreachable Host unreachable for precedence
host-redirect Host redirect
host-tos-redirect Host redirect for TOS
host-tos-unreachable Host unreachable for TOS
host-unknown Host unknown
host-unreachable Host unreachable
information-reply Information replies
information-request Information requests
