892 | Layer 2
www.dell.com | support.dell.com
Figure 30-12. Example of Output of show vlan id
Table 30-4. show vlan Information
Column Heading Description
(Column 1 — no heading) asterisk symbol (*) = Default VLAN
G = GVRP VLAN
P = primary VLAN
C = community VLAN
I = isolated VLAN
NUM Displays existing VLAN IDs.
Status
Displays the word
Inactive for inactive VLANs and the word
Active for active VLANs.
Q
Displays G for GVRP tagged, M for member of a VLAN-Stack VLAN, T
for tagged interface, U (for untagged interface), x (uncapitalized x) for
Dot1x untagged, or
X (capitalized X) for Dot1x tagged.
Ports
Displays the type, slot, and port information. For the type, Po = port
channel,
Gi = gigabit ethernet, and Te = ten gigabit ethernet.
FTOS# show vlan id 40
Codes: * - Default VLAN, G - GVRP VLANs
Q: U - Untagged, T - Tagged
x - Dot1x untagged, X - Dot1x tagged
G - GVRP tagged, M - Vlan-stack
NUM Status Description Q Ports
40 Active M Gi 13/47
FTOS#show vlan id 41
Codes: * - Default VLAN, G - GVRP VLANs
Q: U - Untagged, T - Tagged
x - Dot1x untagged, X - Dot1x tagged
G - GVRP tagged, M - Vlan-stack
NUM Status Description Q Ports
41 Active T Gi 13/47
FTOS#show vlan id 42
Codes: * - Default VLAN, G - GVRP VLANs
Q: U - Untagged, T - Tagged
x - Dot1x untagged, X - Dot1x tagged
G - GVRP tagged, M - Vlan-stack
NUM Status Description Q Ports
42 Active U Gi 13/47
FTOS#
