186 Adding and Replacing Parts
NOTICE: To prevent damage to the memory module connector, do not use tools to
spread the memory-module securing clips.
3
If you are replacing a memory module, remove the existing module:
a
Use your fingertips to carefully spread apart the securing clips on each
end of the memory module connector until the module pops up.
b
Remove the module from the connector at a 45-degree angle.
book.book Page 186 Tuesday, August 28, 2007 10:20 AM
