210 Adding and Replacing Parts
Removing the Display Panel
CAUTION: Before you begin the following procedure, follow the safety
instructions in the
Product Information Guide
.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by touching an unpainted metal surface on the computer.
1
Follow the instructions in "Before Working Inside Your Computer" on
page 180.
2
Remove the display assembly (see "Removing the Display Assembly" on
page 200).
3
Remove the display bezel (see "Removing the Display Bezel" on page 206).
4
Loosen the captive ground screw that attaches the display-panel ground
wire to the display back cover.
1 display panel 2 M2 x 3-mm screws (8)
3 display back cover 4 grounding wire and captive screw
1
2
3
4
