206 Adding and Replacing Parts
Removing the Display Bezel
CAUTION: Before you begin the following procedure, follow the safety
instructions in the
Product Information Guide
.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface (such as the
back panel) on the computer.
1
Follow the instructions in "Before Working Inside Your Computer" on
page 180.
2
Remove the display assembly (see "Removing the Display Assembly" on
page 200).
1 shoulder screws (4), two at the top
and two at the bottom)
2 screw covers (2)
3 M2.5 x 5-mm screws (4), one on
each corner)
4 rubber screw-covers/display
bumpers (6)
5 display bezel
3
5
4
1
2
book.book Page 206 Tuesday, August 28, 2007 10:20 AM
