220 Adding and Replacing Parts
7
Replace the display assembly (see "Replacing the Display Assembly" on
page 203).
8
Replace the keyboard (see "Keyboard" on page 198).
9
Replace the hinge cover (see "Replacing the Hinge Cover" on page 198).
Speakers
Removing the Speakers
CAUTION: Before you begin the following procedure, follow the safety
instructions in the
Product Information Guide
.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface (such as the
back panel) on the computer.
NOTICE: To help prevent damage to the system board, remove the main battery
(see "Before Working Inside Your Computer
" on page 180) before working inside the
computer.
1
Follow the instructions in "Before Working Inside Your Computer" on
page 180.
2
Remove the hinge cover (see "Removing the Hinge Cover" on page 197).
3
Remove the display assembly (see "Replacing the Display Assembly" on
page 203).
4
Remove the keyboard (see "Keyboard" on page 198).
5
Remove the palm rest (see "Removing the Palm Rest" on page 217).
NOTICE: Handle the speakers with care to help prevent damage to them.
6
Disconnect the speaker cable connector from the connector on the system
board.
7
Lift the tape that secures the speaker cables to the computer base, and
disengage the cables from the cable guides.
8
Remove the four M2.5 x 5-mm screws from the speakers (two on each
speaker).
9
Remove the speakers.
book.book Page 220 Tuesday, August 28, 2007 10:20 AM
