196 Adding and Replacing Parts
NOTICE: To help prevent damage to the system board, remove the main battery
(see "Before Working Inside Your Computer" on page 180) before working inside the
computer.
NOTE: If you ordered an internal card with Bluetooth wireless technology with
your computer, the card is already installed.
1
Follow the instructions in "Before Working Inside Your Computer" on
page 180.
2
Remove the M2.5 x 8-mm screw and remove the card cover from the
computer.
3
Pull the card out of the compartment so that you can disconnect the card
from its cable and remove it from the computer.
1 card connector 2 internal card with Bluetooth wireless
technology
3 card door 4 M2.5 x 8-mm screw
3
2
1
book.book Page 196 Tuesday, August 28, 2007 10:20 AM
