Adding and Replacing Parts 229
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface (such as the
back panel) on the computer.
NOTICE: To help prevent damage to the system board, remove the main battery
(see "Before Working Inside Your Computer" on page 180) before working inside the
computer.
1
Follow the instructions in "Before Working Inside Your Computer" on
page 180.
2
Remove the hinge cover (see "Removing the Hinge Cover" on page 197).
3
Remove the keyboard (see "Keyboard" on page 198).
4
Remove the display assembly (see "Removing the Display Assembly" on
page 200).
5
Remove the palm rest (see "Removing the Palm Rest" on page 217).
NOTE: Remove the video card/thermal-cooling assembly as a single unit. Do not
separate the thermal-cooling assembly from the video card.
6
Loosen the four captive screws on the video card/thermal-cooling
assembly.
7
Lift the video card/thermal-cooling assembly from the system board.
NOTE: The appearance of the video card/thermal-cooling assembly may vary,
depending on your computer configuration.
book.book Page 229 Tuesday, August 28, 2007 10:20 AM
