266 Specifications
Cards supported ExpressCard/34 (34 mm) and
ExpressCard/54 (54 mm)
ExpressCard connector size 26 pins
Memory
Memory module connector two user-accessible SODIMM connectors
Memory module capacities 512 MB, 1 GB, and 2 GB
Add-in flash memory card 1 GB, Type 1 Mini-Card support limited to
Microsoft Vista
Memory type 1.8 V SODIMM DDR-II
supports DDR-II 667 MHz up to 4 GB,
w/36-bit addressing
Minimum memory 1 GB (via 2 x 512 MB SoDimms)
Maximum memory 4 GB (via 2 x 2 GB SoDimms)
NOTE: In order to obtain dual-channel
bandwidth capability, both memory slots must
be populated with the same size memory
modules.
5-in-1 media memory card reader
5-in-1 media memory card controller Ricoh R5C833
5-in-1 media memory card connector 5-in-1 combo card connector
Cards supported MS
MS Pro
SD/SDIO
MMC
xD
CD Type I/II & IBM Microdrive through
ExpressCard adapter
ExpressCard
(continued)
book.book Page 266 Tuesday, August 28, 2007 10:20 AM
