Dell SCv3000 Deployment Guide

Congure Emulex HBA Settings
Congure Emulex HBA settings to enable the HBA to communicate more eectively with the Storage Center. Congure Emulex HBA
settings with the Emulex HBAnywhere utility or the Emulex LightPulse BIOS. After conguring the settings based on the manufacturer of
the HBA, congure the settings that apply to the operating system running on the server.
Congure an Emulex HBA to match the following settings:
Table 16. Emulex HBA Settings
Field Setting
NodeTimeOut 60
QueueDepth 255
Topology Value that provides Point-to-Point
QLogic HBAs
Qlogic manufactures HBAs that are compatible with Storage Centers.
NOTE: For more information regarding the compatibility of an HBAs, see the Dell EMC Compatibility Matrix for SC, PS, and FS
Series Arrays. For more information about QLogic, see www.qlogic.com
Congure QLogic HBA Settings
Congure QLogic HBA settings to enable the HBA to communicate more eectively with the Storage Center. The following settings can be
congured on any of the compatible QLogic HBAs from the QLogic Fast!UTIL BIOS or the QLogic SANsurfer. After conguring the settings
based on the manufacturer of the HBA, congure the settings that apply to the operating system running on the server.
QLogic Fibre Channel HBAs
Congure a QLogic Fibre Channel HBA to match the following settings:
Table 17. Fibre Channel HBA Settings
Field Settings
Connection options 1 for point-to-point only
Login retry count 60 attempts
Port down retry count 60 attempts
Link down timeout 30 seconds
Execution Throttle 256
QLogic iSCSI HBAs
Congure a QLogic iSCSI HBA to match the following settings:
HBA Server Settings
103

Dell SCv3000 Specifications

General

HDD speed	10000 RPM
Storage drive size	3.5 \
Storage drive capacity	900 GB
Storage drive interface	Serial Attached SCSI (SAS)
Storage drives installed	Yes
Installed storage drive type	HDD
Total installed storage capacity	6.3 TB
Maximum supported storage capacity	- TB
Number of storage drives installed	7
Number of storage drives supported	16
USB connectivity	-
Chassis type	Rack (3U)
Product color	Black, Grey
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power supply unit (PSU) capacity	1485 W
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 80 %
Dell E-Value Code	SCv3000FC

Weight and Dimensions

Depth	785 mm
Width	445 mm
Height	133.3 mm
