Dell SCv3000 Deployment Guide

Item Control/Feature Icon Description
1 I/O card slot
Fibre Channel I/O card – Ports are numbered 1 to 4 from left to right
• The LEDs on the 16 Gb Fibre Channel ports have the following meanings:
– All o – No power
– All on – Booting up
– Blinking amber – 4 Gbps activity
– Blinking green – 8 Gbps activity
– Blinking yellow – 16 Gbps activity
– Blinking amber and yellow – Beacon
– All blinking (simultaneous) – Firmware initialized
– All blinking (alternating) – Firmware fault
• The LEDs on the 32 Gb Fibre Channel ports have the following meanings:
– All o – No power
– All on – Booting up
– Blinking amber – 8 Gbps activity
– Blinking green – 16 Gbps activity
– Blinking yellow – 32 Gbps activity
– Blinking amber and yellow – Beacon
– All blinking (simultaneous) – Firmware initialized
– All blinking (alternating) – Firmware fault
iSCSI I/O card – Ports are numbered 1 to 4 from left to right
NOTE
: The iSCSI I/O card supports Data Center Bridging (DCB), but
the mezzanine card does not support DCB.
• The LEDs on the iSCSI ports have the following meanings:
– O – No power
– Steady Amber – Link
– Blinking Green – Activity
SAS I/O card – Ports are numbered 1 to 4 from left to right
The SAS ports on SAS I/O cards do not have LEDs.
2
Identication LED Blinking blue continuously – A command was sent to the storage system to make
the LED blink so that you can identify the storage system in the rack.
The identication LED blinks on the control panel of the chassis, which allows
users to nd the storage system when looking at the front of the rack.
The identication LEDs on the storage controllers also blink, which allows users to
nd the storage system when looking at the back of the rack.
3 Cache to Flash (C2F)
• O – Running normally
• Blinking green – Running on battery (shutting down)
4 Health status
• O – Unpowered
• Blinking amber
– Slow blinking amber (2s on, 1s o) – Controller hardware fault was
detected. Use Storage Manager to view specic details about the
hardware fault.
– Fast blinking amber (4x per second) – Power good and the pre-operating
system is booting
• Blinking green
– Slow blinking green (2s on, 1s o) – Operating system is booting
About the SCv3000 and SCv3020 Storage System 21

Dell SCv3000 Specifications

General

HDD speed	10000 RPM
Storage drive size	3.5 \
Storage drive capacity	900 GB
Storage drive interface	Serial Attached SCSI (SAS)
Storage drives installed	Yes
Installed storage drive type	HDD
Total installed storage capacity	6.3 TB
Maximum supported storage capacity	- TB
Number of storage drives installed	7
Number of storage drives supported	16
USB connectivity	-
Chassis type	Rack (3U)
Product color	Black, Grey
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power supply unit (PSU) capacity	1485 W
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 80 %
Dell E-Value Code	SCv3000FC

Weight and Dimensions

Depth	785 mm
Width	445 mm
Height	133.3 mm
