ASDA-B2 Chapter 7 Servo Parameters
Revision September 2013 7-77
Bit9
Bit9:
0: Alarm output (DO function 0x11)
1: Error output (DO function 0x07)
P2-67
JSL Stable Inertia Estimating Time
Address: 0286H
0287H
Operation
Interface:
Keypad/Software Communication
Related Section: N/A
Default: 1.5 15
Control
Mode:
ALL
Unit: 1 times 0.1 times
Range: 0 ~ 200.0 0 ~ 2000
Data Size: 16-bit
Display
Format:
One-digit Decimal
Input Value
Example:
1.5 = 1.5 times 15 = 1.5 times
Settings:
In semi-auto tuning mode, after the servo drive continuously perform the adjustment
for a period of time which is determined by P2-67, the system will consider that the
system inertia has become stable and finish the operation of system inertia
estimation.
