Chapter 7 Servo Parameters ASDA-B2
7-82 Revision September 2013
P3-08■
MNS Monitor Mode
Address: 0310H
0311H
Operation
Interface:
Keypad / Software Communication
Related Section:
Section 8.2
Default: 0000
Control
Mode:
ALL
Unit: N/A
Range: refer to the description of Settings
Data Size: 16-bit
Display
Format:
Hexadecimal
Settings:
This parameter is used to monitor the data of the servo drive via communication. The
monitor data can be displayed on PC upon the data scope function provided by
ASDA-Soft software.
Word - - Low High
Function - - Monitor mode
Range 0 0 0 0 ~ 3
H: Monitor mode, the value must be within the range from 0 through 3.
0: Disabled, i.e. disable monitor function.
1: Reserved.
2: High-speed monitor mode. The sampling time is 2000 times per second and 4
channels can be monitored.
3: High-speed monitor mode. The sampling time is 4000 times per second and 2
channels can be monitored.
P3-09
Reserved (Do Not Use)
Address: 0312H
0313H
P3-10
Reserved (Do Not Use)
Address: 0314H
0315H
P3-11
Reserved (Do Not Use)
Address: 0316H
0317H
