ASDA-B2 Chapter 10 Specifications
Revision September 2013 10-5
Model: ECMA Series
C△04 C△06 C△08 C△09 C△10
01 02 04 04 07 07 10 10 20
Brake release time
[ms (Max)]
5 10 10 10 10 10 10 10 10
Brake pull-in time
[ms (Max)]
25 70 70 70 70 70 70 70 70
Vibration grade (um) 15
Operating temperature 0 ~ 40
o
C
Storage temperature -10 ~ 80
o
C
Operating humidity 20% to 90% RH (non-condensing)
Storage humidity 20% to 90% RH (non-condensing)
Vibration capacity 2.5G
IP rating
IP65 (when waterproof connectors are used, or when an oil seal is used to be
fitted to the rotating shaft (an oil seal model is used))
Approvals
Footnote:
*1 Rate torque values are continuous permissible values at 0~40
o
C ambient temperature when
attaching with the sizes of heatsinks listed below:
ECMA-__04 / 06 / 08 : 250mm x 250mm x 6mm
ECMA-__10 : 300mm x 300mm x 12mm
ECMA-__13 : 400mm x 400mm x 20mm
ECMA-__18 : 550mm x 550mm x 30mm
Material type : Aluminum – F40, F60, F80, F100, F130, F180
*2 The holding brake is used to hold the motor shaft, not for braking the rotation. Never use it for
decelerating or stopping the machine.
*3 For the specifications of the motors with rotary magnetic encoders, please refer to the
specifications of the corresponding standard models.
*4 (△) in
the mode of servo motor indicates the type of encoder. △ = 1: increment, 20-bit; △= 2:
increment, 17-bit.
NOTE
1) Please refer to Section 1.2 for details about the model explanation.
